Product Details:
|
| CPU: | Intel®Celeron™ J900 | USB: | 1x USB3.0/3 X USB2.0 |
|---|---|---|---|
| System: | Windows7, Windows10, Linux | Brightness: | 350 Cd/cm² |
| Screen: | 15.0" Full HD TFT | Angle Of View: | (L) 80/ (R) 80 / (T) 80 / (B) 80 |
| Working Tempetature: | 0 ~ 50° C (32~113°F) | Operating Temperature: | -20 ~ 60° C (-4 ~ 140°F) |
| High Light: | 10 Point Touch Tablet TFT,10 Point Touch Tablet IP65,15 Inch Panel PC FCC |
||
OEM 15 inch Tablet 1024*768,10 point touch Windows10 Linux X86 IPC
|
system parameter
|
CPU |
Intel®Celeron™ J900 |
|
frequency |
2.0GHz |
|
|
Running memory |
Support DDR3L-1333 MHz, 1 * SO-DIMM Slot, Up to 8GB |
|
|
EMMC |
1 * mSATA(3.0) |
|
|
I/O port |
network |
2*Realtek® 1Gbps PCIe Ethernet Controller, RJ-45以太网接口 |
|
Mic |
Realtek® HDA Codec, with MIC/Line-out |
|
|
USB |
1x USB3.0/3 x USB2.0 |
|
|
Serial port |
4 x RS-232； 2 x RS-232 / RS-485 |
|
|
expansion slot |
1 * SATA3.0 7+15P Connector/2*Mini-PCIe (1*mSATA, 1*Wifi+4G) |
|
|
I/O port |
1 x VGA / 1 x HDMI/2 x GLAN / 4 x USB / Line-out / Mic-in/DC-IN |
|
|
|
Dimension (W x H x D) |
361mm x285mm x 52mm |
|
hole size (W x H) |
346mm x 272mm |
|
|
Net Weight |
3.56kg |
|
|
Operating System |
Operating System |
Windows7, Windows10, Linux, |
|
Power |
Input voltage |
12VDC (12-24VDC) |
|
MaximPower Consumption |
25W |
|
|
Display |
screen |
15.0" Full HD TFT |
|
Resolving power |
1024×768 |
|
|
Color Dispay |
16.7MB |
|
|
Backlight |
LED |
|
|
Backlight life |
50000hrs |
|
|
Pixel pitch |
0.297×0.297 |
|
|
Luminance |
350 cd/cm² |
|
|
Contrast |
700 : 1 |
|
|
View angle |
(L) 80/ (R) 80 / (T) 80 / (B) 80 |
|
|
Environmental parameter |
Working temperature |
0 ~ 45° C (32~113°F) |
|
0 ~ 50° C (32~113°F) ；-20 ~ 60° C (-4 ~ 140°F) (RT) |
||
|
Operating Temperature |
-20 ~ 60° C (-4 ~ 140°F) |
|
|
Relative humidity |
10~95% RH@40°C,non-condensing |
|
|
Vibration |
SSD applied: 1.5 Grms, 5 ~ 500 Hz, 1 hr/axis |
|
|
EMC |
CE/FCC Class B |
|
|
waterproof |
IP65 |
